Six post guides high-speed precision punch

Performance Features
High rigidity design in machine frame,adopt with high strength casting,processed by eliminating internal stress.High-strength casting iron body sub-structure leads to good rigidity and small deformation.Sensitive and strong strength,compact design of the clutch and brake
The machine has dynamic balanced system, which can reduce the vibration and noise,extend die life,improve the work environment.Balanced center of gravity
Crankshaft,sawtooth group are adopted with high strength alloy steel,heat process,grinding and other precision processing.New clutch and brake drive part of the body to maintain the heat balance,good heat dissipation.
Adopt with high sensitive&reliable clutch,braking device,assure the accuracy of location and the safety of operation.
Stretched catheter,use the steel of precompressed bolt to make the dynamic,static precision transcend precision stunt,extend die life.
Adopt with forced lubricating cooling system,reduce base thermal strain,assure products’quality,extend machine life

Standard Configuration

Electrodynamic height adjustment Height showing precision 0.01mm Inch positioning device The computer can remember 30 sets Mold processing data Group 3 control in batch Group 2 miss inspection Interlock and single action have 0 degree and 90 degree locating function Main engine reversion set Oil pressure slider locking device

Lubricating oil-cooling cycle machine Disconnect-type clutch and brake Independent electric cabinet Working box Working light Main engine motor is controlled by the converter

Optional Configuration

Bottom dead center precision detector Quick exchange of die device Oil pressure lifting device High-speed feeder Double-end oil-pressure uncoiler

Bump-cutter discharging machine Air-cushion quakeproof device Constant voltage Front and back sound-proof safety gate
