Close double-crankshaft precision punch

Release date: 2019-09-18 10:50:53 Visits: 627

Close double-crankshaft  precision punch
Performance Features
It adopts the work center of high alloy steel, double crankshaft and two width, connecting rod structural support and optimal design.
In order to guarantee relative stability when the machine is working, adopt the design of symmetry of two balancers.
The precision of mold adjustment is as high as 0.1mm, safe, convenient and reliable.
Such parts as crankshaft, gear set and connecting rod, after hard oxidation, mill and other fabrication processing, have extreme comprehensive mechanical performance and durable function.
Adopt highly sensitive and reliable clutch/brake units and international top duplex magnetic valves and overload protection device, to guarantee the precision and safety of press slider revolving and stopping.
Reasonable physical design is convenient to realize automatic production, reduce cost and increase efficiency.
Advanced design concept, low noise, low consumption and saving energy.


Standard Configuration

Oil-pressure overload protection device
Electrodynamic-type slider adjusting device
Electrodynamic height indicator
Slider and die balancing device
Rotated cam switch
Crankshaft angle indicator
Counter
Air source contact
Second falling protector
Air blowing device
Mechanical quakeproof foot
     Miss inspection device
Main motor inversion set
Photo-electricity safety protection device
Converter
Slider and die balancing device
Touch screen control device
Electrodynamic-type butter lubricating device
Die lighting device

Optional Configuration

Vapor-pressure die backer device
Quick exchange of die device(die lifter, die clamper or die mover)
Cam top material device
Automatic feeding device(feeder, Material frame, straightening machine)
Foot switch
