Open single crank precision punch
Release date: 2019-09-18 10:12:49 Visits: 569

With high rigidity design in machine frame, the machine is welded of high-quality steel sheets and treated by tension elimination to improve stability and reliability of the machine.
Keep the transmission center and that of the whole machine in conformity, to guarantee precision and stability of pressing.
In order to guarantee relative stability when the machine is working, adopt the design of symmetry of two balancers.
The precision of mold adjustment is as high as 0.1mm, safe, convenient and reliable.
Such parts as crankshaft, gear set and connecting rod, after hard oxidation, mill and other fabrication processing, have extreme comprehensive mechanical performance and durable function.
Adopt highly sensitive and reliable clutch/brake units and international top duplex magnetic valves and overload protection device, to guarantee the precision and safety of press slider revolving and stopping.
Reasonable physical design is convenient to realize automatic production, reduce cost and increase efficiency.
Advanced design concept, low noise, low consumption and saving energy.
Standard Configuration
Oil-pressure overload protection device
HM slider adjusting device(below ET60)
Electrodynamic-typeSlideradjusting device(above ET80)
Frequency-conversion and variable speed motor(speed controlled)
Mechanical height indicator(below ET60)
Digital height indicator(above ET80)
Slider and mold balancing device
Rotated cam controller
Crankshaft angle indicator
Electromagnetic-type counter
Air source contact
Second falling protector
Air blowing device
Mechanical quakeproof foot
Miss inspection device
Maintenance tools and tool cabinet
Main motor inversion set
Photoelectricity safety protection device
Power socket
Electrodynamic-type butter lubricating device
Touch screen(prejudge and preload)
Optional Configuration
Vapor-pressure-typediebacker device
Foot switch
Quick exchange of die device
(die lifter, die clamper or die mover)
Top of slider material device
Feeder (air, machine and NC)
Bump-cutter machine
Mechanical arm
Die lighting device
Material frame
Thin oil lubricating device
